3 說明
BQ24725A 是一款高效同步的電池充電器，所含組件數較少，適用于空間受限的多化合物電池充電 應用。
BQ24725A 利用兩個電荷泵分別驅動 N 溝道 MOSFET（ACFET、RBFET 和 BATFET），從而自動選擇系統電源。
SMBus 控制的輸入電流、充電電流和充電電壓 DAC 具有很高的調節精度，該精度可通過系統電源管理微控制器輕松編程。
BQ24725A 使用內部輸入電流寄存器或外部 ILIM 引腳來調節 PWM 調制，以減小充電電流。
BQ24725A 可對 1 節、2 節、3 節或 4 節串聯鋰電子電池充電。
- 如需了解所有可用封裝，請參閱產品說明書末尾的可訂購產品附錄。
